TYPE-A 4 PIN RIGHT ANGLE 10MM FEMALE USB SOCKET

Send Inquiry

Request To Call Back

TYPE-A 4 PIN RIGHT ANGLE 10MM FEMALE USB SOCKET

Price 1.50 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

TYPE-A 4 PIN RIGHT ANGLE 10MM FEMALE USB SOCKET Specification

Material
Metal Shell, Plastic Housing

Application
PCB Mount, Data Communication, Charging Ports, Embedded USB Interfaces

Connector
USB Type-A Right Angle Female Socket

Voltage Rating
30V DC

Female End Type
Type-A USB Female

Temperature
-40C to +85C

Connector Type
Right Angle, Through-Hole Solder Mount

Capacity
Supports USB Standard Data/Power Levels

Pairs
Single Pair

Length
N/A (Connector Only)

Insulation
Thermoplastic

Sheild
Unshielded

Number of Conductor
4

Wire Gauge
Standard USB, Typically 28AWG Data/24AWG Power

Color
Silver (Metal Shell), Black Housing

Jacket Material
N/A (Connector Only)

Outer Diameter
10mm

Cable Type
N/A (Socket Only)

Flame Resistance Level
UL94V-0

Contact Resistance
Maximum 30m

Port Type
USB 2.0 Compatible

Protection
Dust Resistant

Body Size
Approximate 15.7mm 14.5mm 10mm

Mounting Style
Right Angle, Through Hole

Insulation Resistance
Minimum 1000M (at 500V DC)

Contact Material
Copper Alloy with Gold Plating

Current Rating
1.5A Max

Durability
1500 Mating Cycles Min

TYPE-A 4 PIN RIGHT ANGLE 10MM FEMALE USB SOCKET Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About TYPE-A 4 PIN RIGHT ANGLE 10MM FEMALE USB SOCKET

Brand

Connector Type	Female
USB Type	UCB
Current Rating	0.5A
Connector Orientation	AS PER DEMAND
Mounting Type	STANDARD
Piece per box	1000
Minimum Order Quantity	100 Piece

Consumer Electronics: Power switches in radios, flashlights, and toys.
Industrial Equipment: Control switches for machinery and equipment.
Automotive: Control switches for lights, wipers, and other systems.
Telecommunication Devices: Signal routing and selection.
Computers and Peripherals: Mode selection, reset switches, and power control.

Reliable USB 2.0 Connectivity

This female USB Type-A right angle socket is engineered for stable data transfer, supporting USB 2.0 standards. Its gold-plated copper alloy contacts ensure a low contact resistance, maximizing signal integrity and minimizing power loss. The durable plastic housing and metal shell make it a reliable choice for a wide range of electronic applications.

Versatile Right-Angle Mounting

The right-angle, through-hole mounting style facilitates efficient PCB integration, especially in compact designs. Its orientation helps reduce space usage, making it a go-to solution for embedded systems, charging stations, and various devices requiring a secure, space-saving USB port.

Enhanced Durability and Safety

Designed to withstand at least 1,500 mating cycles, this connector delivers longevity even in frequent-use scenarios. The UL94V-0 flame-resistant thermoplastic and dust-resistant body ensure safety and reliable performance in challenging environments, while supporting a wide operating temperature range from -40C to +85C.

FAQs of TYPE-A 4 PIN RIGHT ANGLE 10MM FEMALE USB SOCKET:

Q: How is the TYPE-A 4 PIN RIGHT ANGLE FEMALE USB SOCKET mounted onto a PCB?

A: This socket utilizes a right-angle, through-hole solder mount, which means it is inserted into pre-drilled holes in the PCB and secured through soldering. This ensures strong mechanical stability for both data and power transfer.

Q: What are the key benefits of using a gold-plated copper alloy for the contacts?

A: Gold-plated copper alloy contacts offer excellent conductivity, minimize contact resistance (maximum 30m), and provide corrosion resistance. This enhances signal integrity and extends the lifespan of the connector.

Q: When should I select an unshielded USB socket like this model?

A: Choose this unshielded socket when electromagnetic interference is minimal or controlled in your device environment, or where board space and cost constraints are a priority over shielding needs.

Q: Where is this USB socket commonly used?

A: It is widely used in PCB-mounted applications such as embedded USB interfaces, charging ports on electronic devices, industrial equipment, and data communication terminals.

Q: What process should be followed to ensure a secure connection with this socket?

A: Ensure proper through-hole soldering during assembly and confirm that the socket aligns with the PCB layout. Use the specified wire gauges and maintain correct mating force for reliable contact and durability.

Q: How does the socket provide protection against dust and flames?

A: The connector is built with a dust-resistant design and uses UL94V-0 rated thermoplastic insulation. This combination helps protect internal components from environmental contaminants and reduces fire risks in electronic assemblies.

Q: What are the maximum electrical and environmental limits for this USB socket?

A: The socket supports currents up to 1.5A, voltages up to 30V DC, operates reliably between -40C and +85C, and offers insulation resistance of at least 1000M at 500V DC, ensuring safety and performance in diverse conditions.
