6 PIN 2.54MM PITCH MALE FEMALE JST CONNECTOR

Send Inquiry

Request To Call Back

6 PIN 2.54MM PITCH MALE FEMALE JST CONNECTOR

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

6 PIN 2.54MM PITCH MALE FEMALE JST CONNECTOR Specification

Temperature
-25°C to +85°C

Male End Type
JST Plug (Header)

Connector Type
Crimp Style Connector, JST XH Series

Material
Copper (Conductor), Nylon (Connector housing)

Capacity
Up to 3A per contact

Application
PCB Connections, Battery Packs, Prototyping, Robotics, Electronics

Voltage Rating
250V AC/DC

Female End Type
JST Receptacle (Socket)

Pairs
Single Set (Male & Female)

Connector
JST 6 Pin 2.54mm Pitch Male & Female

Flame Resistance Level
UL94V-0

Cable Type
Flat Ribbon Cable

Wire Gauge
26 AWG

Outer Diameter
1.3mm (individual wire)

Length
Customizable (default 15cm)

Number of Conductor
6

Sheild
No Shield

Insulation
PVC Insulated

Color
Black / Multicolor

Jacket Material
PVC

Cable Length
150mm (Standard), Custom lengths available

Contact Resistance
20m

Number of Pins
6

RoHS Compliance
Yes

Termination Type
Crimp/Solder

Insulation Resistance
>=1000M at 500V DC

Contact Material
Tin plated brass

Housing Material
Nylon 66 UL94V-0

Current Rating
3A max per pin

Mounting Type
Cable Mount (Free Hanging)

Mating Cycles
500 times

Humidity Resistance
Up to 95% RH (non-condensing)

Pitch
2.54mm

6 PIN 2.54MM PITCH MALE FEMALE JST CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 6 PIN 2.54MM PITCH MALE FEMALE JST CONNECTOR

Pitch	2.5 mm
Brand	NO
Part Number	JST12
Connector Gender	MALE FEMALE
Contact Material	PLASTIC
Current Rating	STANDARD
Minimum Order Quantity	100 Piece

Applications:
- Used in battery connections, LED lighting, computer hardware, and hobby electronics.
- Suitable for compact and lightweight electronic devices.
Advantages:
- Reliable and secure connections with locking mechanisms to prevent disconnection.
- Compact and space-saving design.
- Easy to assemble and disassemble without special tools.

Reliable and Adaptable Connector System

This 6-pin JST connector offers strong electrical performance, supporting up to 3A per contact and 250V AC/DC, making it suitable for demanding applications in electronics, robotics, prototyping, and battery assemblies. Its cable mount, free-hanging design and crimp/solder termination provide flexibility for various project requirements. Housing made from flame-resistant nylon ensures long-term safety and structural integrity.

Durability and Safety Certified

The connector assembly is engineered for durability, rated for up to 500 mating cycles, and is compliant with RoHS safety standards. Its insulation resistance of 1000M at 500V DC and the humidity resistance of up to 95% RH make it dependable in diverse operating environments. The PVC insulated flat ribbon cable and nylon housing ensure both flame resistance and mechanical stability.

FAQs of 6 PIN 2.54MM PITCH MALE FEMALE JST CONNECTOR:

Q: How is the 6 PIN 2.54mm JST connector typically used?

A: This connector is widely used in PCB connections, battery packs, prototyping setups, robotics, and other electronic projects requiring secure and compact multi-wire connections.

Q: What are the benefits of the crimp/solder termination type?

A: Crimp/solder termination provides a secure, low-resistance connection that minimizes the risk of disconnection, making it reliable for applications involving movement or vibration.

Q: When should I consider customizing the cable length for my application?

A: Customizing the cable length is recommended when the standard 150mm does not fit your design layout or enclosure, ensuring neat and efficient wiring in your specific setup.

Q: Where can this JST connector be installed or mounted?

A: This connector is designed for cable mount (free hanging) installations, allowing you to position it within devices, harnesses, or equipment where panel or PCB mounting is not required.

Q: What is the process for proper termination of this connector?

A: To terminate, strip the 26 AWG wires, crimp or solder the contacts, then insert them into the nylon housing. Double-check for secure connection and correct polarity before use.

Q: What advantages does the nylon 66 UL94V-0 housing provide?

A: Nylon 66 UL94V-0 offers outstanding flame resistance and mechanical durability, ensuring device safety even at elevated temperatures or in demanding electrical conditions.

Q: How does the connector maintain performance in humid environments?

A: With a humidity resistance of up to 95% RH (non-condensing) and robust insulation, the connector remains functional and reliable in moist operational settings.
