12X12X18 MM 4 PIN BLACK TACTILE SWITCH

Get a Price/Quote

MOQ : 1000 Pieces

12X12X18 MM 4 PIN BLACK TACTILE SWITCH Specification

Max. Current
50 mA Megaampere ( MA)

Rated Voltage
DC 12V Volt (V)

Protection Level
IP40

Finish Type
Matte

Number of Module
1

Circuit Type
SPST (Single Pole Single Throw)

Automation Grade
Manual

Temperature Range
-20C to +70C Celsius (oC)

Product Type
Tactile Switch

Material
Black thermoplastic, copper alloy contacts

Insulation Resistance
100 M at 500VDC

Contact Resistance
100 m Milliohm (m)

Max. Voltage
DC 12V Volt (V)

Operating Temperature
-20C to +70C Celsius (oC)

Stoke
2.5 mm (typical)

Size
12x12x18 mm

Color
Black

Weight
Approx. 3g Grams (g)

Mounting Type
Through-hole

Current Rating
50 mA

No Of Poles
Single Pole

12X12X18 MM 4 PIN BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 12X12X18 MM 4 PIN BLACK TACTILE SWITCH

Current Rating	5 Amp
Insulation resistance	NO
IP Rating	3A
Minimum Order Quantity	1000 Piece

Applications: Commonly used in consumer electronics, keyboards, remote controls, automotive controls, and medical devices.
Durability: Designed for high-reliability with many models rated for thousands to millions of actuation cycles.
Mounting Options: Available in surface-mount (SMT) or through-hole (THT) configurations for PCB integration.

Reliable Performance

Engineered for consistency, the tactile switch delivers dependable operation up to 100,000 mechanical cycles. Its dielectric strength of 250VAC for one minute and rated load of DC 12V, 50mA demonstrate its suitability for various electronic applications, even in demanding environments.

Easy and Versatile Installation

The through-hole mounting design ensures straightforward integration into PCBs, with copper alloy terminals providing excellent connectivity. Its compact size and matte black finish make it suitable for modern electronic products and control modules, enhancing both aesthetics and functionality.

Environmental and User Safety

RoHS compliance affirms the switch is free from harmful substances, aligning with international safety standards. It maintains insulation resistance at 100 M and operates efficiently within temperatures from -20C to +70C, ensuring both device integrity and user protection.

FAQs of 12X12X18 MM 4 PIN BLACK TACTILE SWITCH:

Q: How is the 12X12X18 MM 4 Pin Black Tactile Switch installed onto circuit boards?

A: This tactile switch is designed for through-hole mounting, allowing for secure and easy integration into standard printed circuit boards (PCBs) using manual soldering or automated assembly processes.

Q: What types of devices typically use this tactile switch?

A: The switch is commonly utilized in electronic gadgets, control panels, instrumentation, and industrial equipment, anywhere reliable momentary input and tactile feedback are required.

Q: When should I choose this tactile switch for my project?

A: Select this switch when your project demands a compact, responsive, and environmentally safe solution, especially for low-voltage DC applications with operating currents up to 50 mA.

Q: Where can this tactile switch be sourced from in India?

A: It is available from reputed distributors, exporters, importers, manufacturers, and traders across India, supporting both small-scale and bulk purchases for diverse applications.

Q: What is the process for ensuring environmental compliance with this tactile switch?

A: The switch complies with RoHS standards, meaning it is manufactured without hazardous substances and meets strict environmental requirements for responsible electronics production.

Q: How does the switch improve usability and device lifecycle?

A: Its tactile feedback, fast response time of less than 20 ms, and robust construction enhance user interaction while the mechanical life of at least 100,000 cycles ensures long-term reliability.

Q: What are the benefits of its IP40 protection rating?

A: An IP40 rating safeguards the switch against small solid objects, making it suitable for most indoor applications while maintaining operational dependability during routine use.
