Send Inquiry6X6X10MM 4 PIN BLACK TACTILE SWITCH
Price 1 INR/ Piece
MOQ : 1000 Pieces
6X6X10MM 4 PIN BLACK TACTILE SWITCH Specification
- Protection Level
- IP40
- Rated Voltage
- 2A Ampere (A)
- Temperature Range
- -20C to +70C Celsius (oC)
- Mechanical Life
- 100,000 Cycles Days
- Number of Module
- Single
- Finish Type
- Matt
- Automation Grade
- Manual
- Response Time
- 1 ms Seconds
- Max. Current
- 50 mA Milliampere (mA)
- Circuit Type
- Single Circuit
- Product Type
- Tactile Switch
- Material
- Plastic Housing, Copper Alloy
- Insulation Resistance
- 100 M at 500V DC
- Contact Resistance
- 100 m Milliohm (m)
- Max. Voltage
- 3V Volt (V)
- Operating Temperature
- -20C to +70C Celsius (oC)
- Stoke
- 1.8 mm
- Size
- 6x6x10 mm
- Color
- BLACK
- Weight
- TACT SWITCH GSM (gm/2)
- Mounting Type
- Through Hole
- Current Rating
- 50 mA
- No Of Poles
- Single Pole
6X6X10MM 4 PIN BLACK TACTILE SWITCH Trade Information
- Minimum Order Quantity
- 1000 Pieces
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID)
- Supply Ability
- 999999 Pieces Per Day
- Delivery Time
- 5 Days
- Sample Available
- Yes
- Sample Policy
- Sample costs shipping and taxes has to be paid by the buyer
- Main Domestic Market
- All India
About 6X6X10MM 4 PIN BLACK TACTILE SWITCH
| Current Rating |
|
| Voltage Rating |
|
| ROHS Compliance |
|
| Material |
|
| Switch Type |
|
| Minimum Order Quantity |
|
- Applications: Commonly used in consumer electronics, keyboards, remote controls, automotive controls, and medical devices.
- Durability: Designed for high-reliability with many models rated for thousands to millions of actuation cycles.
- Mounting Options: Available in surface-mount (SMT) or through-hole (THT) configurations for PCB integration.
Versatile Design for Multiple Applications
This tactile switch is engineered for flexibility, fitting into a wide range of electronic circuits. Its compact 6x6x10mm size and through-hole mounting ensure straightforward integration onto PCBs, while the round button profile enhances user ergonomics. Suited for both consumer gadgets and industrial controls, it offers designers ample convenience.
High-Reliability Performance
Built with silver-plated contacts and a robust mechanical life of up to 100,000 cycles, this switch guarantees consistent operation in demanding environments. The swift response time of 1 ms and low contact resistance ensure precise and reliable switching, making it ideal where quick, accurate feedback is required.
Safe and Compliant Operations
With dielectric strength of 250V AC, insulation resistance of at least 100 M at 500V DC, and RoHS compliance, the switch is engineered to meet strict safety and environmental standards. Its ability to withstand a soldering temperature of 260C (max for 5s) supports efficient assembly, while its IP40 rating provides protection against solid particles.
FAQs of 6X6X10MM 4 PIN BLACK TACTILE SWITCH:
Q: How do I mount the 6x6x10mm 4 Pin Black Tactile Switch on a circuit board?
A: This tactile switch is designed for through-hole mounting. Insert the four pins into the designated holes on your PCB and solder them in place, ensuring the temperature does not exceed 260C for more than 5 seconds to prevent any damage.Q: What benefits does the silver-plated contact material provide for this tactile switch?
A: Silver-plated contacts reduce contact resistance, enhance electrical conductivity, and improve long-term durability, leading to better switch performance and a reliable signal transmission over the devices lifespan.Q: Where can I use this tactile switch?
A: The 6x6x10mm switch is suitable for a variety of applications, including control panels, consumer electronic devices, instrumentation, and industrial equipment where momentary actuation and compact size are required.Q: When is this switch ideal for use in a project?
A: This switch is ideal when you need a reliable, momentary actuator with a swift response time (1 ms) and moderate actuation force, especially in projects requiring up to 100,000 mechanical operations and compliance with RoHS standards.Q: What process ensures safe soldering of this switch?
A: To solder this switch safely, maintain a soldering temperature of no more than 260C for up to 5 seconds. This protects the plastic housing and ensures the integrity of the internal components.Q: What are the operating and storage temperature ranges for this tactile switch?
A: The switch operates reliably from -20C to +70C and can be stored safely between -30C and +80C, making it suitable for standard electronics environments.
