12X12X21MM 4 PIN BLACK TACTILE SWITCH

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12X12X21MM 4 PIN BLACK TACTILE SWITCH Specification

Max. Current
50mA

Circuit Type
SPST (Single Pole Single Throw)

Rated Voltage
12V DC

Mechanical Life
100,000 cycles

Protection Level
IP40

Automation Grade
Manual

Temperature Range
-25C to +70C

Finish Type
Matte

Number of Module
1 Module

Response Time
<1ms

Product Type
Tactile Switch

Material
Plastic (Body), Metal (Contacts)

Insulation Resistance
100M min. at 500V DC

Contact Resistance
50m max.

Max. Voltage
12V DC

Operating Temperature
-25C to +70C

Stoke
2.5mm

Size
12x12x21 mm

Color
Black

Weight
Approx. 2g

Mounting Type
Through Hole

Current Rating
50mA

No Of Poles
1 Pole

12X12X21MM 4 PIN BLACK TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 12X12X21MM 4 PIN BLACK TACTILE SWITCH

Mounting Type	SMD
Current Rating	3V
Voltage Rating	2A
ROHS Compliance	No
Material	PLASTIC
Switch Type	Tact
Minimum Order Quantity	1000 Piece

Applications: Ideal for industrial machinery, security systems, automotive applications, and sensitive electronic equipment.
Customization: Available in various key configurations, sizes, and mounting options to meet specific security needs.
Durability: Constructed with high-quality materials to withstand harsh environments and frequent use.

Compact and Durable Design

Engineered for long-term performance, this tactile switch features a robust plastic body combined with silver-plated alloy contacts. Its mechanical life spans up to 100,000 cycles, ensuring reliable actuation for repeated use in control panels, consumer devices, and industrial applications.

Precise Performance

With a controlled initial force of 18050gf and 2.5mm stroke, the switch delivers consistent tactile feedback. It boasts a bounce time of 5ms, a response time under 1ms, and high insulation resistance, making it suitable for demanding electronic circuits requiring accurate pulse signals.

Versatile Applications

This 4 pin round button tactile switch is designed for manual automation, offering SPST momentary action. Its through-hole mounting supports easy integration into PCBs, making it perfect for developers, manufacturers, and repair services across diverse industries. The switch operates reliably in temperatures ranging from -25C to +70C.

FAQs of 12X12X21MM 4 PIN BLACK TACTILE SWITCH:

Q: How is the 12X12X21MM 4 Pin Black Tactile Switch commonly used?

A: This tactile switch is widely used in electronic control systems for momentary switching applications, such as reset, start, or input functions in consumer electronics, industrial equipment, and DIY projects.

Q: What are the benefits of the silver-plated alloy contacts in this switch?

A: Silver-plated alloy contacts provide excellent conductivity and resistance to oxidation, ensuring low contact resistance, high signal integrity, and long-term reliability for the switch.

Q: When should this switch be selected over other types?

A: Choose this switch when you require a momentary SPST function with tactile feedback, a compact form factor, and reliable operation in moderate environmental conditions for up to 100,000 mechanical cycles.

Q: Where is the 12X12X21MM tactile switch typically installed?

A: It is generally mounted on printed circuit boards via through-hole technology in devices such as control panels, embedded systems, small appliances, and instrumentation.

Q: What process is involved in mounting the switch?

A: Installation involves placing the switchs four pins through matching PCB holes and securing it by soldering, ensuring stable electrical connection and mechanical retention.

Q: How does the switch perform under varying temperatures?

A: Engineered with robust materials, the switch can operate efficiently within a temperature range of -25C to +70C and can be safely stored from -30C to +80C without performance degradation.

Q: What advantages does its RoHS compliance offer?

A: RoHS compliance certifies that the switch is manufactured without hazardous substances, making it environmentally friendly and suitable for use in global markets adhering to strict safety regulations.
