IMPORTED POTENTIOMETER BEND PIN D CUT 15 MM

Send Inquiry

Request To Call Back

IMPORTED POTENTIOMETER BEND PIN D CUT 15 MM

Price 20 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

IMPORTED POTENTIOMETER BEND PIN D CUT 15 MM Specification

Humidity %
<85% RH (non-condensing)

Insulation Material
Plastic

Connector Type
Solder lug, bend pin

Surface Finish
Nickel-plated shaft

IP Rating
Not rated

Overheating Protection
NO

Operating Temperature
-10C to +60C

Power Factor
N/A (Passive Component)

Feature
D-cut shaft, easy mounting, smooth rotation

Mounting Type
Panel mount, through-hole PCB mounting

Shape
Cylindrical

Product Type
Rotary potentiometer

Application
Volume and tone control, electronic circuits

Frequency (MHz)
DC to low MHz range (analog applications)

Rated Voltage
50V DC

Energy Consumption
N/A (Passive Component)

Output Type
Variable resistance

Color
Black knob, silver metal

Dimension (L*W*H)
15 mm (shaft length)

Weight
12 g

Phase
Single

Size
15 mm

Input Voltage
Up to 50V DC

Connection Type
Bend pin, through-hole

No Of Poles
3

Material
Metal shaft, plastic body

Resistance Range
10k Ohm (common), other values available

Storage Temperature
-25C to 70C

Shaft Type
D cut

Shaft Diameter
6 mm

Rotation Angle
300

Tolerance
20%

Life Cycle
15,000 cycles (typical)

RoHS Compliant
Yes

IMPORTED POTENTIOMETER BEND PIN D CUT 15 MM Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About IMPORTED POTENTIOMETER BEND PIN D CUT 15 MM

Knob Diameter	13 mm
Power Rating	3 W
Resistance Value	100k Ohm
Usage/Application	Electronic Appliances
I am interested in	Linear Potentiometer
Brand	IMPORTED
Voltage	STANDARD
Material	METAL
Color	MULTI
Rated Power	STANDARD
Size/Dimension	AS PER PHOTO
Type	TONE
Minimum Order Quantity	2000 Piece

Description:

Long knurled and split shaft

Perfect for replacing and upgrading volume and tone controls

A250K/B250K-ohm mini control pot

Coarse knurled shaft fits most control knobs

Suitable for LP electric guitar with 18mm potentiometer

Specification:

Material: Acrylic & Metal

Shaft Length: 18mm

Shaft Diameter: 7mm

Base Diameter: 17mm

Knobs Diameter: 26mm

Color: Gold

Package Includes:

2 Pieces A250K Potentiometer

2 Pieces B250K Potentiometer

4 Pieces Knobs

Note:

Color might be slightly different due to the color calibration of each individual monitor.

Please allow slightly measuring deviation due to manual measurement

Reliable D Cut Shaft Design

This potentiometer comes with a 6mm D-cut metal shaft, providing secure fitment for knobs and smooth, controlled rotation. Its 15mm shaft length makes it suitable for most panel depths, facilitating easy installation in control panels or audio equipment.

Versatile Application and Mounting

Suited for volume and tone control, as well as other electronic adjustments, it is engineered for through-hole PCB or panel-mount configurations. Bent pins ensure a firm connection to circuit boards, while solder lug terminals allow straightforward and reliable wiring.

Durability and Compliance

With RoHS compliance and a life cycle rating of 15,000 typical cycles, the potentiometer supports sustainable manufacturing and long-term reliability in operational environments ranging from -10C to +60C and humidity levels below 85% RH (non-condensing).

FAQs of IMPORTED POTENTIOMETER BEND PIN D CUT 15 MM:

Q: How do I mount the Imported Potentiometer Bend Pin D Cut 15mm in my circuit?

A: This potentiometer is designed for panel mount or through-hole PCB installation. Use the bend pin terminals to solder directly onto your circuit board, or secure the shaft through a panel hole for easy integration and knob attachment.

Q: What are the common applications of this potentiometer?

A: The main uses include volume and tone control in audio equipment, variable resistance in analog electronic circuits, and adjustment settings in control devices. Its DC to low MHz range supports most analog applications.

Q: When should I use a D-cut shaft potentiometer?

A: A D-cut shaft is best chosen when a secure, non-slip knob fit is required, improving alignment and preventing slippage during repetitive adjustments. This is ideal for user-facing controls in amplifiers or instrument panels.

Q: Where can I obtain potentiometers with resistance values other than 10k Ohm?

A: While 10k Ohm is the most commonly available resistance, other values can be sourced through distributors, exporters, importers, or manufacturers, especially in the Indian electronics market.

Q: What is the typical life cycle of this potentiometer and what benefits does it provide?

A: It is rated for approximately 15,000 cycles, ensuring longevity and consistent performance for applications with frequent adjustment needs.

Q: How does the RoHS compliance benefit my project?

A: RoHS compliance ensures that no hazardous substances are present, contributing to environmental safety and easier regulatory approvals for your products.

Q: What is the process for connecting the potentiometer to a PCB?

A: Insert the bent pins into the corresponding PCB holes, making sure the orientation matches your design, and solder carefully for a sturdy electrical and mechanical connection.
