76 MM Slide Potentiometer 4591 G

Price 50 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

76 MM Slide Potentiometer 4591 G Specification

Feature
Smooth sliding action, long life

Humidity %
Up to 85% RH, non-condensing

Efficiency
Standard

Mounting Type
Panel mount

Connector Type
2 or 3 terminal

IP Rating
Not rated

Operating Temperature
-10C to +70C

Surface Finish
Metallic and matte finish

Insulation Material
Plastic

Overheating Protection
NO

Shape
Rectangular

Product Type
Slide Potentiometer

Application
Volume control, audio mixers, industrial equipment

Protection Level
Standard

Rated Voltage
250V max

Energy Consumption
Negligible

Output Type
Analog

Color
Black and silver

Dimension (L*W*H)
76mm x 9mm x 7mm

Weight
Approx 40 grams

Size
76 mm

Phase
Single Phase

Material
Plastic and metal

No Of Poles
Single

Connection Type
Solder Lugs

76 MM Slide Potentiometer 4591 G Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 76 MM Slide Potentiometer 4591 G

Resistance Range	50v
Voltage	0.5W
Material	CARBON
Lenght	75mm
Usage / Apllication	ELECTRONICN APPLIANCE
Minimum Order Quantity	1000

This is a sliding potentiometer. It is commonly used as the volume control in audio power amplifiers. When you move the slider from one side to the other, its output voltage will range from 0V to the voltage range you apply. This potentiometer has a long open slot to allow the wiper lug to move freely up and down.

Reliable Adjustable Control for Diverse Applications

Engineered for precision, the 76 MM Slide Potentiometer 4591 G is tailored to suit needs in audio, industrial, and control interfaces. Its durable build combines plastic and metal for long-lasting use, while the customizable resistance values fit a variety of circuit designs. With straightforward panel mounting and analog output, its a trusted solution for professional hardware and OEMs.

Outstanding Endurance and Smooth Operation

Benefit from over 10,000 reliable adjustment cycles thanks to its carbon track and copper alloy wiper. The potentiometer is designed for smooth, consistent sliding without degradation, ensuring accurate performance in demanding environments. Its robust operation under temperatures ranging from -10C to +70C allows reliable integration into both consumer and industrial devices.

FAQs of 76 MM Slide Potentiometer 4591 G:

Q: How do I install the 76 MM Slide Potentiometer 4591 G?

A: Installation is straightforward with its panel-mount design and solder lugs. Position the potentiometer in your panel cutout and secure it, then solder the terminals for reliable electrical connections.

Q: What are the usage scenarios for this slide potentiometer?

A: This potentiometer is ideal for volume control systems, audio mixers, and industrial meters where smooth analog adjustment is needed. Its long life and efficient performance make it suitable for both professional audio and industrial environments.

Q: When should I consider replacing the potentiometer?

A: The product is rated for a life expectancy of over 10,000 adjustment cycles. Consider replacing if you experience inconsistent resistance, erratic output, or physical wear after extensive use.

Q: Where can I use the slide potentiometer with respect to environmental limits?

A: This potentiometer can be used in environments ranging from -10C to +70C and humidity up to 85% RH (non-condensing), but it does not offer IP-rated protection, so avoid harsh, wet, or dusty locations.

Q: What benefits does the carbon track technology provide?

A: The carbon track ensures smooth sliding action, stable resistance adjustments, and long operational life, making it ideal for applications requiring reliable and frequent usage.

Q: Is a slider knob included, and how does it affect use?

A: A slider knob is not included with this potentiometer. Users may select a compatible knob for easier manual operation and improved control, depending on their application preferences.

Q: What is the process for selecting resistance value options?

A: The standard total resistance is 10k, but other values are available upon request when ordering. Specify your preferred value to the distributor, exporter, or manufacturer for customization.
