12 PIN ON-OFF WHITE WITH OUT SCREW

Price 7 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

12 PIN ON-OFF WHITE WITH OUT SCREW Specification

Temperature Range
-10C to +60C

Max. Current
10A

Rated Voltage
250V AC

Protection Level
IP20

Finish Type
Glossy

Automation Grade
Manual

Circuit Type
ON-OFF

Number of Module
1

Mechanical Life
>50,000 cycles

Response Time
<20ms

Product Type
12 Pin ON-OFF Switch (White, Without Screw)

Material
High-grade Polycarbonate Housing, Copper Alloy Contacts

Insulation Resistance
>1000M at 500V DC

Contact Resistance
<50m

Max. Voltage
250V AC

Operating Temperature
-10C to +60C

Stoke
Standard Linear Stroke

Size
53mm x 23mm x 18mm (Approx)

Color
White

Weight
36g

Mounting Type
PCB Mount (Without Screw)

Current Rating
10A

No Of Poles
12

Vibration Resistance
10~55Hz, 1.5mm amplitude

Switch Type
Rocker

Shock Resistance
150m/s2 (15G)

Panel Cutout
49mm x 19mm

Terminal Type
Solder Lug

RoHS Compliance
Yes

Dielectric Strength
1500V AC for 1 min

Contact Material
Silver Plated Copper

Application
Electrical Panel Switchboards, Machinery Control

12 PIN ON-OFF WHITE WITH OUT SCREW Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 12 PIN ON-OFF WHITE WITH OUT SCREW

Material	Brass
Shape	LONG
Styles	ON - OFF
Product Type	POWER SWITCH
Color	Black
Finishing	GOOD
Size	STANDARD
Brand	NO
Quantity Per Pack	100
Minimum Order Quantity	100 Piece

12 PIN ON-OFF WHITE KNOB WITHOUT SCREW.

12-pin on-off power switch featuring a distinctive yellow knob design.
Screwless installation for quick and hassle-free setup.
Provides easy on-off functionality for various electronic devices.

Rugged Construction for Industrial Use

Featuring a robust polycarbonate body and copper alloy contacts, this switch is constructed to perform reliably in challenging environments. Its silver-plated contacts and IP20 protection level make it ideal for machinery control and electrical panels, ensuring safety and efficiency even under heavy-duty use.

Easy, Secure, Screwless Installation

The rocker switch is designed for quick mounting with a 49mm x 19mm panel cutout size, allowing for secure installation without screws. Its solder lug terminals facilitate efficient PCB integration, improving assembly speed and reducing maintenance complexities.

Outstanding Durability and Compliance

Engineered for a long operating life, the switch surpasses 50,000 cycles and is RoHS compliant, reflecting its commitment to sustainability. Its high shock and vibration resistance ensures dependable performance in dynamic industrial setups.

FAQs of 12 PIN ON-OFF WHITE WITH OUT SCREW:

Q: How do I install the 12 PIN ON-OFF White Rocker Switch without using screws?

A: This switch features a PCB mount design that does not require screws. Simply prepare a 49mm x 19mm panel cutout and insert the switch; use the solder lug terminals for secure electrical connections.

Q: What applications is this switch best suited for?

A: It is ideal for electrical panel switchboards and machinery control, thanks to its robust dielectric strength, shock and vibration resistance, and reliable ON-OFF circuit type.

Q: What are the benefits of silver-plated copper contacts?

A: Silver plating enhances conductivity and reduces contact resistance, ensuring efficient current flow and minimal heat build-up for long-lasting performance.

Q: Where is this switch commonly used?

A: This product is used internationally across industries, primarily by manufacturers and technicians in India for control panels and machinery integration.

Q: What is the process to ensure optimal safety and performance?

A: Follow proper mounting instructions, ensure correct soldering of terminals, and operate within the specified temperature and voltage ranges to maximize safety and efficiency.

Q: When should this switch be replaced or serviced?

A: Replace the switch if you notice a significant increase in contact resistance, operational difficulty, or after extensive usage beyond its rated mechanical life of over 50,000 cycles.
