2.54 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER

Send Inquiry

Request To Call Back

2.54 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER

Price 15 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

2.54 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER Specification

Connector
Female Header

Connector Type
Straight

Application
PCB Board Interfacing, Electronics Prototyping

Voltage Rating
250V AC/DC

Male End Type
Compatible with 2.54 mm Male Pin Header

Female End Type
Single Row Female

Temperature
-40C to +105C

Material
Phosphor Bronze, Gold Plated

Outer Diameter
2.54 mm

Jacket Material
Plastic

Color
Black

Flame Resistance Level
UL94V-0

Insulation
High Temperature Plastic

Length
Standard

Pitch
2.54 mm

Body Material
Thermoplastic/PA6T UL94V-0

Contact Resistance
20 m max

No. of Pins
Available from 2 to 40 pins (single row)

Current Rating
3A max

Insulation Resistance
1000 M at 500V DC

Withstanding Voltage
600V AC/minute

Operating Humidity
0% - 95% RH

Standard
Complies with international PCB connector specifications

Packaging Type
Tube & bulk pack available

RoHS Compliance
Yes

Mounting Type
Through Hole

Durability
500 mating cycles

Contact Plating
Gold plated (10\\

Row Configuration
Single Row

2.54 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 2.54 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER

Size	2 mm
Number Of Pins	AS PER DEMAND
Color	BLACK
Circuit	YES
Material	PLASTIC
Application	BERG CONNECTOR
brand	NO
Connector Type	BERG STRIP
Minimum Order Quantity	100 Piece

Applications:
- Commonly used in computer hardware, such as connecting motherboard components.
- Suitable for wire-to-board and board-to-board connections.
Advantages:
- Reliable electrical connection.
- Easy to use and solder onto printed circuit boards (PCBs).
- Available in various pin counts and configurations to suit different needs.

Reliability Through Gold-Plated Contacts

This pin header features high-quality gold plating on the contacts, offering superior corrosion resistance and exceptionally low contact resistance. The design ensures stable, long-term connections for your electronic projects, reducing signal loss and extending connector lifespan even under frequent use or harsh conditions.

Versatile Configurations for Varied Applications

Available in single row configurations from 2 up to 40 pins, the connector fits a range of PCB board interfacing needs. Its standard 2.54 mm pitch and compatibility with male headers make it suitable for electronics prototyping, repair, and other board-to-board connections. The flame-retardant body material ensures usage in high-temperature, safety-critical environments.

Robust Construction for Demanding Environments

Built from thermoplastic/PA6T UL94V-0, this header offers high mechanical and flame resistance while maintaining insulation at elevated temperatures. It withstands humidity levels up to 95% RH and a broad temperature range, ensuring performance in most industrial or laboratory settings.

FAQs of 2.54 MM SINGLE ROW FEMALE GOLD PLATED PIN HEADER:

Q: How is the 2.54 MM Single Row Female Gold Plated Pin Header typically used in electronic projects?

A: This pin header serves as a reliable connector for interfacing PCB boards, commonly used in electronics prototyping, module interconnections, and repair tasks where secure and removable board-to-board links are required.

Q: What are the benefits of gold plating on the contact pins?

A: Gold plating, at 10 or as specified, ensures low contact resistance, improved conductivity, and robust protection against oxidation, resulting in longer lifespan and more reliable connections under repeated mating cycles.

Q: Where can I use this single row female header regarding environmental conditions?

A: You can use this header in environments with high humidity (0% 95% RH) and a broad temperature range (-40C to +105C). Its also suitable for areas where flame resistance is mandated, thanks to its UL94V-0 rating.

Q: What is the process for mounting the connector on a PCB?

A: The header uses a through-hole mounting design. Simply align the pins with the corresponding holes on your PCB, insert them, and secure the connection by soldering the pins on the opposite side for a durable and stable attachment.

Q: When should I consider the mechanical durability of this connector?

A: If your application requires frequent plugging and unplugging, you will benefit from this connectors durability of over 500 mating cycles, ensuring consistent performance without mechanical failure.

Q: What packaging options are available for distributors or bulk buyers?

A: The headers are available in both tube and bulk pack formats, providing flexibility for component distributors, exporters, importers, and manufacturers requiring scalable packaging solutions.

Q: How does RoHS compliance benefit my products?

A: RoHS compliance ensures the absence of hazardous substances, making your finished products safer and globally marketable by meeting international environmental standards.
