3X6x3.5 mm2 pin smd white Tactile Switch

Send Inquiry

Request To Call Back

3X6x3.5 mm2 pin smd white Tactile Switch

Price 2 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

3X6x3.5 mm2 pin smd white Tactile Switch Specification

Response Time
<5 ms

Circuit Type
Normally Open (NO)

Protection Level
IP40

Mechanical Life
100,000 cycles

Finish Type
Matte / Black painted housing

Number of Module
1

Temperature Range
-20C to +70C

Rated Voltage
12V DC

Max. Current
50mA

Automation Grade
Manual

Product Type
Tactile Switch (SMD)

Material
Plastic, Metal (Copper Alloy Contacts)

Insulation Resistance
>=100M at 100V DC

Contact Resistance
<100m max

Max. Voltage
12V DC

Operating Temperature
-20C to +70C

Stoke
0.25 0.10 mm

Size
3x6x3.5 mm

Color
White

Weight
~0.06g

Mounting Type
Surface Mount (SMD)

Current Rating
50mA @ 12V DC

No Of Poles
Single Pole

Actuator Type
Round, Flat Top

Terminal Type
Gull-wing, SMD

Contact Material
Silver-plated alloy

ESD Protection
8 kV (air discharge)

RoHS Compliance
Compliant

Travel Force
160gf 30gf

Switch Height
3.5mm

Application
Consumer Electronics, Remote Controls, Keyboards, Wearables

Reflow Soldering Capability
Yes

Storage Temperature
-40C to +85C

Humidity Range
85% RH (non-condensing)

Dielectric Withstand Voltage
250V AC for 1 minute

3X6x3.5 mm2 pin smd white Tactile Switch Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

About 3X6x3.5 mm2 pin smd white Tactile Switch

Buy the inestimable 3X6x3.5 mm2 pin SMD white Tactile Switch at an unbeatable price. Masterful in design, this switch features a highly recommended silver-plated alloy contact, ensuring optimal conductivity and reliability. Its best-in-class gull-wing SMD terminals facilitate secure mounting and efficient reflow soldering. With a travel force of 160gf 30gf, flat top round actuator, and impressive ESD protection of 8 kV, it supports robust applications. RoHS compliance, IP40 protection, and a mechanical life of 100,000 cycles make it ideal for remote controls, wearables, keyboards, and consumer electronics.

Applications and Versatile Usage

The 3X6x3.5 mm2 pin SMD white Tactile Switch excels in both specific and general use, making it perfect for remote controls, consumer electronics, keyboards, and wearables. Due to its superior build quality and compact size, it is also suitable for innovative electronic gadgets, control panels, and customized projects. This tactile switch ensures precise operation, making it a trusted solution for automation systems, portable devices, and industry-standard equipment.

Supply Ability, Certifications, and Sample Availability

Rated highly among distributors and manufacturers, the 3X6x3.5 mm2 pin SMD white Tactile Switch is supplied quickly with shipped goods reaching national and international markets. Certified for RoHS compliance, it meets stringent environmental standards. Shipment processes are streamlined, and samples are readily available on request for evaluation. The switch is consistently stocked, ensuring uninterrupted supply and timely distribution for any volume requirement.

FAQs of 3X6x3.5 mm2 pin smd white Tactile Switch:

Q: How is the 3X6x3.5 mm2 pin SMD white Tactile Switch best used in consumer electronics?

A: This switch is highly recommended for consumer electronics such as remote controls, keyboards, and wearables, offering reliable tactile feedback and durability, which enhances user experience.

Q: What certifications does the 3X6x3.5 mm2 pin SMD white Tactile Switch hold?

A: The switch is RoHS compliant, ensuring that it adheres to environmental safety standards and can be shipped worldwide without restriction.

Q: When can I expect shipment after placing an order for this tactile switch?

A: Shipment is processed promptly after order confirmation, with supply ability supporting fast national and international delivery for any required quantities.

Q: Where is this tactile switch primarily distributed and sourced?

A: The switch is widely available through distributors, exporters, manufacturers, importers, and traders in India, with significant international reach.

Q: What is the process for obtaining a sample of the 3X6x3.5 mm2 pin SMD Tactile Switch?

A: Samples are available upon request through authorized distributors or manufacturers to allow customers to evaluate compatibility with their applications.
