6X6X5 MM 2 PIN LG RED TACTILE SWITCH

Get a Price/Quote

MOQ : 1000 Pieces

6X6X5 MM 2 PIN LG RED TACTILE SWITCH Specification

Number of Module
1

Response Time
<5 ms

Max. Current
50 mA

Mechanical Life
100,000 cycles min.

Automation Grade
Manual

Rated Voltage
12V DC

Circuit Type
SPST-NO (Single Pole Single Throw - Normally Open)

Finish Type
Matte / Glossy Plastic Surface

Protection Level
IP40

Temperature Range
-25C ~ +70C

Product Type
Tactile Switch

Material
High-grade Plastic, Metal Contacts

Insulation Resistance
100 M min. (at 500V DC)

Contact Resistance
100 m max.

Max. Voltage
12V DC

Operating Temperature
-25C to +70C

Stoke
0.25 mm

Size
6x6x5 mm

Color
Red (Cap)/Black (Body)

Weight
Approx. 0.3g

Mounting Type
Through Hole

Current Rating
50 mA at 12V DC

No Of Poles
Single Pole

Cap Shape
Round Flat Top

Applications
Consumer Electronics, Remote Controls, DIY Projects, Embedded Systems

Compliant Standards
RoHS, REACH

Switch Travel
0.25 mm 0.1mm

Storage Temperature
-40C to +85C

Contact Material
Silver Alloy

Actuation Force
160gf 30gf

Terminal Material
Silver-plated brass

Pin Number
2

6X6X5 MM 2 PIN LG RED TACTILE SWITCH Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Main Domestic Market
All India

6X6X5 MM 2 PIN LG RED TACTILE SWITCH About

The rare and supreme 6X6X5 MM 2 PIN LG RED TACTILE SWITCH is a new benchmark for consumer electronics, remote controls, and embedded systems. Designed with a lustrous red cap and black body, its opulent performance includes a special actuation force of 160gf30gf and precision 0.25 mm travel. Crafted using high-grade plastic and silver-plated brass terminals, this RoHS and REACH-compliant switch boasts a robust IP40 protection level. Experience the special rate of this durable switch, engineered for reliability across 100,000 mechanical cycles and broad temperature resilience.

Versatile Features and Application Environments

This tactile switch is favored for its supreme mechanical life, swift response time, and IP40 dust resistance. Its round flat top cap and matte/glossy finish enhance tactile interaction. Commonly deployed in consumer electronics, its opulent build also suits remote controls, DIY innovations, and embedded systems. From tech labs to home devices, it excels across diverse application media with its robust insulation and compact form.

Sample Access, Payment Flexibility, and Secure Packaging

Samples of the 6X6X5 MM 2 PIN LG RED TACTILE SWITCH can be requested for preliminary evaluation, subject to applicable charges and transportation costs. Flexible payment terms are available to suit varying business requirements. Each switch is carefully packaged using protective material, ensuring reliability and safety during transport services to your location, whether for distributor, importer, or direct manufacturer needs.

FAQs of 6X6X5 MM 2 PIN LG RED TACTILE SWITCH:

Q: How can this tactile switch benefit my project or application?

A: The switch offers high durability, a lustrous finish, and reliable operation even at frequent usage rates, making it ideal for long-term consumer electronics, remote controls, and embedded systems.

Q: What is the process for obtaining a sample of this switch?

A: To obtain a sample, contact the supplier or distributor to request availability. Note that sampling may require a charge as well as transportation costs, based on the location and order specifics.

Q: Where are these tactile switches commonly used?

A: They are commonly used in consumer electronics, remote controls, DIY applications, and embedded systems, thanks to their opulent design, robust insulation, and compact size.

Q: How does the switch ensure reliability in use?

A: With silver alloy contacts, an actuation force rated for 100,000 cycles, and RoHS/REACH compliance, the switch consistently maintains low contact resistance and high insulation, ensuring stable performance.

Q: What payment and packaging options are offered?

A: Flexible payment terms are provided; packaging is secure and protective, ensuring safe delivery using established transport services and options that suit bulk or single unit orders.
