9 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

About 9 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR

• Applications:
  • Used in battery connections, LED lighting, computer hardware, and hobby electronics.
  • Suitable for compact and lightweight electronic devices.
• Advantages:
  • Reliable and secure connections with locking mechanisms to prevent disconnection.
  • Compact and space-saving design.
  • Easy to assemble and disassemble without special tools.


Enduring Performance and Durability

With contact resistance of 20m and insulation resistance of 1000M at 500V DC, this connector maintains exceptional electrical performance across extended use. Its robust build and tin-plated contacts ensure excellent conductivity and resistance to wear, making it reliable for over 500 mating cycles.


Flexible Mounting and Customization

You can mount the connector via through-hole or panel-mount methods, providing versatility for various PCB and panel designs. Its further adaptable thanks to customizable cable lengths and support for AWG 24-28, making it easy to integrate into diverse applications.


Safety and Compliance Assured

This connector adheres to RoHS standards and features UL94V-0 flame resistance, making it safe for standard indoor electrical environments. Its insulation and jacket materials offer additional protection against dust and moisture, supporting up to 95% storage humidity.



FAQs of 9 PIN 2.54MM PITCH MALE FEMALE REPLICATE CONNECTOR:




Q: How do I install the 9 PIN 2.54MM Pitch Male Female Replicate Connector?

A: This connector can be mounted either through-hole or panel mount, facilitating installation on a printed circuit board or a control panel. Ensure correct pin alignment and secure the connection using its friction lock mechanism for a stable fit.



Q: What applications are ideal for this replicate connector?

A: It is designed for data transmission, PCB interconnections, and use in flat ribbon cable assemblies, providing reliable connections for both signal and low-power applications in industrial and commercial electronics.



Q: When should the connector be replaced or inspected?

A: While it supports at least 500 mating cycles, regular inspection is advised, especially in high-vibration or high-use environments. Replace the connector if contact resistance noticeably increases or if physical damage is observed.



Q: Where can I source this connector in India?

A: This product is available through authorized distributors, exporters, importers, and manufacturers across India. Bulk and tray packaging options cater to different supply needs.



Q: What is the process for customizing the cable length?

A: You can request custom lengths during the order process. Specify your desired length, compatible wire gauge (AWG 24-28), and other requirements to ensure the assembly matches your projects specifications.



Q: What are the main benefits of using this connector?

A: Key benefits include high reliability over repeated use, ease of integration with flexible mounting options, RoHS compliance for safety, and support for up to 1A per pin with robust flame and humidity resistance, making it versatile for various electronic setups.
