FUSE THIMBLE FEMALE

Price 4 INR/ Piece

Get a Price/Quote

MOQ : 5000 Pieces

FUSE THIMBLE FEMALE Specification

Sealed
NO

Surface Treatment
Nickel Plated

Cable Diameter
Supports 1.5 mm to 2.5 mm Cables

Thickness
Standard: 0.8 mm

Product Type
Fuse Thimble Female Connector

Material
Brass/Nickel Plated

Application
Used for Holding Fuses Securely in Electrical Circuits

Contact Resistance
5 m

Insulation Resistance
100 M at 500V DC

Diameter
6 mm (Outer)

Terminal Socket
Yes

Style
Thimble

Fittings
Female Connector Type

Rated Voltage
250V AC

Weight
Approx. 5g

Color
Silver

FUSE THIMBLE FEMALE Trade Information

Minimum Order Quantity
5000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About FUSE THIMBLE FEMALE

Voltage	220 V
Current Rating	5 A
Material	SS
Fuse Type	Thimmble
Model Name/Number	07
Product Type	Female Fuse
Minimum Order Quantity	1000

With enriched industrial experience and knowledge, we are providing a qualitative SS 07 Female Fuse Thimmble.

Robust Electrical Performance

Engineered for safety and reliability, the FUSE THIMBLE FEMALE provides high insulation and voltage withstand capacity. It effectively prevents electrical failures even under demanding conditions, making it a trusted choice for secure fuse mounting in both new and retrofit installations.

Versatile Application & Simple Installation

Supporting both crimp and solder connections, this panel mount female thimble fits cable sizes from 1.5 mm to 2.5 mm. Its straightforward installation process and compatibility with commonly used fuse sizes ensure adaptability across multiple electrical setups.

Quality Materials & Safety Compliance

Manufactured from nickel-plated brass, the thimble offers durable construction and superior corrosion resistance. Compliance with flame retardant UL94 V-0 guarantees enhanced safety, making it suitable for critical environments.

FAQs of FUSE THIMBLE FEMALE:

Q: How is the FUSE THIMBLE FEMALE installed in an electrical panel?

A: The FUSE THIMBLE FEMALE is designed for panel mount installation. To install, insert the thimble through the panel opening, secure it according to the mounting requirements, and connect the cable either by crimping or soldering, depending on your application preference.

Q: What cable sizes are compatible with this thimble connector?

A: This connector supports cables with diameters ranging from 1.5 mm to 2.5 mm, making it versatile for a range of electrical circuit requirements.

Q: When should I choose a thimble style female fuse holder over other types?

A: You should select the thimble style when secure, panel-mounted fuse retention and compatibility with standard 6mm outer diameter connectors are important, especially in systems requiring up to 250V AC and enhanced flame retardancy.

Q: Where can the FUSE THIMBLE FEMALE be utilized effectively?

A: It is ideal for use in electrical panels, distribution boxes, and industrial control circuits within industries such as automation, manufacturing, and export/import operations, especially in environments where flame retardancy and secure fuse holding are imperative.

Q: What is the benefit of UL94 V-0 flame retardant compliance?

A: UL94 V-0 rating indicates that the material extinguishes flames quickly and resists catching fire, offering increased safety and regulatory compliance in critical electrical applications.

Q: How does the product ensure secure and reliable electrical contact?

A: The connector features a nickel-plated brass construction, maintaining a low contact resistance (5 m) and high insulation resistance (100 M at 500V DC), ensuring stable electrical connections and preventing overheating or circuit failures.
