10 PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR

About 10 PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR

• Applications:
  • Used in battery connections, LED lighting, computer hardware, and hobby electronics.
  • Suitable for compact and lightweight electronic devices.
• Advantages:
  • Reliable and secure connections with locking mechanisms to prevent disconnection.
  • Compact and space-saving design.
  • Easy to assemble and disassemble without special tools.


Reliable Performance for Demanding Applications

Engineered for secure data transmission and PCB interconnections, this 10-pin connector excels in stability and endurance. Its robust contact materials, gold-over-nickel plating, and flame-retardant housing guarantee consistent performance in challenging environments. With a wide operating temperature and high-insulation resistance, this is the ideal solution for manufacturers and prototypers alike.


Versatile Mounting and Application Options

Designed for through-hole mounting on PCBs, the connector is perfect for a variety of electronic projects. Available as standalone headers or paired with IDC ribbon cables, its adaptability supports fast integration into prototypes, test rigs, and finished products. The dual-row design with 2.54mm pitch ensures compatibility with standard development boards.



FAQs of 10 PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR:




Q: How do I mount the 10 PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR on my PCB?

A: This connector is designed for through-hole PCB mounting, allowing straightforward soldering onto compatible dual-row 2.54 mm pitch layouts. Insert the pins into the corresponding board holes and solder them securely for a stable electrical connection.



Q: What applications is this connector best suited for?

A: It is ideal for PCB interconnections, prototyping, and data transmission tasks. Common applications include development boards, industrial electronics, testing instruments, and data communication interfaces, where reliable multi-pin connectivity is crucial.



Q: When should I opt for this connector over other types?

A: Choose this connector when you require a reliable 10-pin compact connection with robust contact performance, high durability, and compatibility with 2.54mm pitch layouts. Its >=200 mating cycles and gold-over-nickel plating make it ideal for frequent connections and high-reliability requirements.



Q: Where can I buy the 10 PIN 2.54 MM PITCH MALE FEMALE REPLICATE CONNECTOR in India?

A: These connectors are available through multiple channels including distributors, exporters, importers, manufacturers, and electronic traders across India. They can often be sourced from online component suppliers and local electronics markets.



Q: What is the usage process for connecting the male and female headers?

A: Align the male and female connectors to match the pin and socket positions, then gently press them together until fully engaged. For IDC ribbon cable variants, insert the cable into the connector before closing and securing the IDC mechanism.



Q: What are the key benefits of using this connector in electronic projects?

A: Key advantages include high current handling (up to 3A per contact), strong insulation resistance, repeated durability (200 cycles), RoHS compliance, and reliable flame retardant construction. The gold-plated contacts ensure minimal resistance and long-term connectivity.
