DB 37 FEMALE CONNECTOR

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DB 37 FEMALE CONNECTOR Specification

Connector Type
D-subminiature (D-sub), DB37

Capacity
37 pins for signal transmission

Temperature
-55C to +105C

Female End Type
Socket (Receptacle)

Application
Data transmission, industrial automation, control panels, I/O connections

Male End Type
Not included

Material
Connector body: Steel, Insulator: Thermoplastic, Contacts: Copper alloy with gold or tin plating

Pairs
Not applicable (single terminated)

Connector
DB 37 Female

Voltage Rating
250V AC RMS

Number of Conductor
37

Color
Blue (insulator)

Wire Gauge
Accepts 28-20 AWG

Outer Diameter
Dependent on cable used

Insulation
Thermoplastic, UL rated

Flame Resistance Level
UL 94V-0

Sheild
Optional, metal shell provides EMI/RFI protection

Length
Varies, typically as per cable requirements

Jacket Material
PVC or custom as per cable

Cable Type
Multi-conductor, shielded or unshielded

Cable Length
Customizable

Durability
500 mating cycles minimum

Locking Feature
Thumbscrews or jack screws for secure connection

Insulation Resistance
1000 M at 500V DC

Contact Plating
Gold or tin over nickel

Mounting Style
Panel mount, rear or front

Contact Resistance
30 m

Housing Shielding
Stamped steel with nickel plating

RoHS Compliance
Yes

Current Rating
5A max per contact

DB 37 FEMALE CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About DB 37 FEMALE CONNECTOR

Material	Aluminum
Brand	MIPORTED
Part Number	DB12
Connector Type	Female
USB Type	DB
Current Rating	STANDARD
Connector Orientation	STANDARD
Mounting Type	PCV
Piece per box	100
Minimum Order Quantity	100 Piece

Applications:
- Commonly used in computer hardware, such as connecting motherboard components.
- Suitable for wire-to-board and board-to-board connections.
Advantages:
- Reliable electrical connection.
- Easy to use and solder onto printed circuit boards (PCBs).
- Available in various pin counts and configurations to suit different needs

Robust Design for Industrial Applications

The DB 37 Female Connector is engineered for reliability in demanding environments. Its copper alloy contacts plated with gold or tin deliver excellent conductivity and durability over at least 500 mating cycles. The shielded stamped steel shell, paired with a thermoplastic insulator rated UL 94V-0, ensures resilience against EMI/RFI and fire hazards, making it ideal for use in control panels or automation systems.

Flexible Mounting and Installation

With panel mount options for front or rear installation and compatibility with customizable cable lengths, the DB 37 Female Connector supports versatile system configurations. Thumbscrews or jack screws provide secure attachment, while the connector's acceptance of 28-20 AWG wire gauges and both shielded or unshielded multi-conductor cables ensures adaptability for various data transmission needs.

Superior Performance and Safety

Rated for up to 5A per contact and 250V AC RMS, the connector maintains stable transmission with low contact resistance and high insulation resistance. The thermoplastic housing not only resists heat but also meets stringent UL 94V-0 flame resistance standards. Its RoHS compliance and broad operating temperature range (-55C to +105C) guarantee safety and reliability in professional installations.

FAQ's of DB 37 FEMALE CONNECTOR:

Q: How is the DB 37 Female Connector typically mounted?

A: This connector is designed for panel mount installation and can be secured from either the front or rear of the panel using thumbscrews or jack screws, ensuring a tight and stable connection.

Q: What types of cables are compatible with the DB 37 Female Connector?

A: The connector accommodates multi-conductor cables, either shielded or unshielded, with wire gauges ranging from 28 to 20 AWG. The outer diameter and jacket material can be customized based on the cable requirements.

Q: When should I use a DB 37 Female Connector in my application?

A: Choose the DB 37 Female Connector for applications requiring secure, high-density signal transmission-such as data communication, control panels, industrial automation, and electrical I/O connections-especially where panel mounting and EMI/RFI shielding are needed.

Q: Where does the DB 37 Female Connector provide the most benefit?

A: It excels in environments demanding reliable data or signal transmission with protection from electromagnetic interference-commonly used in industrial control panels, automation, and other sensitive electronic equipment.

Q: What is the process for attaching cables to this connector?

A: Wires (28-20 AWG) are typically terminated to the connector contacts via soldering or crimping, depending on the specific connector variant. The connector is then secured to the panel with mounting screws and may be further fixed using thumbscrews or jack screws.

Q: How does the housing shield enhance connector performance?

A: The optional metal shell provides effective EMI/RFI protection, safeguarding signal integrity, especially in electrically noisy environments. This shielding minimizes data loss and interference during operation.

Q: What are the safety and compliance standards met by this connector?

A: The DB 37 Female Connector features UL 94V-0 flame-resistant thermoplastic insulation and is fully RoHS compliant, ensuring safety from fire hazards and the absence of hazardous substances in its construction.
