DB15 FEMALE CONNECTOR

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

DB15 FEMALE CONNECTOR Specification

Female End Type
DB15 Socket

Capacity
Data Transmission

Application
Computer Interfaces, Video, Industrial Equipment

Material
Nickel-Plated Steel & Plastic

Connector Type
Solder Type / Crimp Type

Voltage Rating
250V AC

Connector
DB15 Female

Temperature
-25C to +85C

Outer Diameter
~13 mm (for typical DB15 cable)

Jacket Material
PVC

Number of Conductor
15

Cable Type
Multi-core Round Cable

Sheild
Metallic Shell with Grounding

Length
Depends on cable used (not applicable for connector only)

Color
Blue

Wire Gauge
24 AWG

Insulation
PVC

Flame Resistance Level
UL94V-0

Cable Length
Not Applicable (Connector only)

DB15 FEMALE CONNECTOR Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About DB15 FEMALE CONNECTOR

Number Of Pins	AS PER DEMAND
Color	AS PER ODER
Circuit	YES
Material	METAL
Application	MONITOR/CPU ETC.
brand	IMPORTED
Connector Type	DB CONNECTOR
Minimum Order Quantity	100 Piece

Applications:
- Commonly used in computer hardware, such as connecting motherboard components.
- Suitable for wire-to-board and board-to-board connections.
Advantages:
- Reliable electrical connection.
- Easy to use and solder onto printed circuit boards (PCBs).
- Available in various pin counts and configurations to suit different needs.

High-Quality Materials for Lasting Performance

With gold-plated brass contacts and a nickel-plated steel shell, the DB15 Female Connector is designed to deliver superior conductivity and corrosion resistance. Its high insulation resistance and reliable dielectric strength contribute to stable, long-term operation, while the UL94V-0 rated flame-resistant plastic ensures enhanced safety in demanding environments.

Versatile Applications in Modern Industries

Ideal for use in computer interfaces, video transmission, and industrial machinery, the DB15 Female Connector offers flexibility through both solder and crimp termination. Its 15-pin, 2-row (8+7 arrangement) form factor is compatible with multi-core round cables, supporting data transmission across a broad temperature range of -25C to +85C. The robust locking mechanism ensures secure connections every time.

FAQ's of DB15 FEMALE CONNECTOR:

Q: How is the DB15 Female Connector installed for panel or PCB mounting?

A: The DB15 Female Connector supports both panel mount and PCB mount installations. For panel mounting, position the connector in the designated cutout and secure it using the jackscrew locking mechanism. For PCB mounting, the solder or crimp terminals are connected to the corresponding pads or wires, followed by mechanical securing to the board.

Q: What types of terminations can be used with this connector?

A: This connector accommodates both solder cup and crimp termination styles. Solder cups allow for direct soldering of 24 AWG wires, while crimp contacts can be attached using appropriate crimp tools, providing flexibility for assembly and maintenance.

Q: When should I choose the DB15 Female Connector for my project?

A: Use this connector when you require a durable, reliable interface for data transmission in computer, video, or industrial applications. Its high current and voltage ratings, robust grounding, and compatibility with a wide range of cables make it suitable for demanding operational environments.

Q: Where can I use this DB15 Female Connector?

A: The connector is ideal for deployment in computer interface systems, video transmission setups, and various industrial automation equipment. Its versatility in mounting and termination methods also makes it suitable for new installations and retrofit projects.

Q: What is the process for attaching wires to the connector?

A: Wires can be terminated to the DB15 via soldering into the solder cups or by crimping the corresponding contacts. After wire attachment, assemble the connector shell, ensure proper grounding, and secure it with the jackscrew lock for stable connections.

Q: How does the metallic shield benefit my connections?

A: The metallic shield enhances electromagnetic interference (EMI) protection and provides effective grounding. This reduces signal noise and improves data integrity, which is especially beneficial in industrial and video applications where interference can affect performance.

Q: What advantages does the DB15 Female Connector offer over standard connectors?

A: The DB15 Female Connector offers high durability (500+ mating cycles), low contact resistance, reliable electrical insulation, and environmental safety via RoHS compliance. Its sturdy construction, flexibility in mounting, and flame resistance collectively ensure dependable performance in a variety of professional settings.
