6 PIN ON-OFF WHITE WITHOUT SCREW

Price 6 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

6 PIN ON-OFF WHITE WITHOUT SCREW Specification

Automation Grade
Manual

Protection Level
IP20

Number of Module
1

Temperature Range
-20C to +55C

Response Time
Instant

Max. Current
6A

Circuit Type
ON-OFF

Rated Voltage
250V AC

Finish Type
Matte

Mechanical Life
>10,000 cycles

Product Type
6 Pin ON-OFF Switch

Material
Polycarbonate, Copper Alloy

Insulation Resistance
>100 M at 500V DC

Contact Resistance
<50 m

Max. Voltage
250V AC

Operating Temperature
-20C to +55C

Stoke
2 positions (ON-OFF)

Size
Standard

Color
White

Weight
Approx. 14g

Mounting Type
Panel Mount (Snap Fit)

Current Rating
6A

No Of Poles
Single Pole Double Throw (SPDT)

6 PIN ON-OFF WHITE WITHOUT SCREW Trade Information

Minimum Order Quantity
1000 Pieces

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About 6 PIN ON-OFF WHITE WITHOUT SCREW

Material	Plastic
Color	Black
Usage/Application	Commercial
Shape	Rectangle
Plating	Natural Brass
Minimum Order Quantity	100 Piece

6-pin on-off power switch featuring a distinctive WHITE knob design.
Screwless installation for quick and hassle-free setup.
Provides easy on-off functionality for various electronic devices.

Key Features and Build Quality

This switch boasts a flame-retardant polycarbonate body and copper alloy contacts for durability. The ON-OFF markings are embossed on the actuator, ensuring clear visibility of operational status. Its solder lug terminals and screwless, snap-fit design enable quick, secure panel mounting.

Electrical and Mechanical Specifications

Rated at 250V AC and 6A, the switch provides instant actuation and a mechanical life of over 10,000 cycles. The insulation resistance exceeds 100 M at 500V DC, and its dielectric strength is 1500V AC per minute, supporting safe and reliable operation even under demanding electrical conditions.

Application and Compliance

This Rocker Switch is best suited for automation systems, control panels, and appliances. It meets RoHS standards and incorporates flame-retardant materials, contributing to eco-friendliness and enhanced fire safety. Its IP20 protection level adds to its resilience in diverse environments.

FAQs of 6 PIN ON-OFF WHITE WITHOUT SCREW:

Q: How do I mount the 6 PIN ON-OFF White Rocker Switch into a panel?

A: To mount this switch, use the snap-fit feature designed for easy installation into panels without the need for screws. Simply cut an opening of approximately 22mm x 13mm on your panel and press the switch into place until it securely fits.

Q: What benefits does the screwless design offer?

A: The screwless, snap-fit design allows for faster and safer installation, reducing assembly time and eliminating issues related to loose screws. This is especially advantageous for mass production and maintenance scenarios.

Q: Where can this rocker switch be used?

A: This switch is ideal for control panels, home appliances, automation systems, and industrial equipment requiring manual ON-OFF control. Its robust structure and flame retardance make it suitable for various environments.

Q: What is the maximum electrical load the switch can handle?

A: The switch is rated for up to 6A at 250V AC, supporting a wide range of electronic and electrical devices that require reliable ON-OFF switching.

Q: When should I consider replacing this switch?

A: Although the mechanical life exceeds 10,000 cycles, replacement should be considered if you detect abnormal resistance, visible damage, or degradation in switching response over time.

Q: Is the switch compliant with environmental and safety standards?

A: Yes, this switch is RoHS compliant and made from flame-retardant materials, ensuring both environmental responsibility and safety.

Q: What makes the ON-OFF marking on the actuator advantageous?

A: The embossed ON-OFF marking provides clear operational guidance and reduces the risk of user error, enhancing usability and safety during manual operation.
