9.5MM PITCH 2 PIN BARRIER TERMINAL CONNECTOR

About 9.5MM PITCH 2 PIN BARRIER TERMINAL CONNECTOR

• Applications:
  • Used in battery connections, LED lighting, computer hardware, and hobby electronics.
  • Suitable for compact and lightweight electronic devices.
• Advantages:
  • Reliable and secure connections with locking mechanisms to prevent disconnection.
  • Compact and space-saving design.
  • Easy to assemble and disassemble without special tools.


Reliable Performance and Safety

This barrier terminal connector is flame-retardant (UL94V-0) and supports a maximum voltage of 300V, ensuring both electrical safety and consistent performance in demanding environments. With a dielectric withstand of 2000V AC/minute and insulation resistance of 500 M, it is suitable for industrial and power distribution requirements.


Versatile Application and Construction

Its 2-position capacity, robust steel-zinc plated screws, and tin-plated brass contacts offer secure and vibration-resistant connections for stranded or solid wires. The 9.5mm pitch fits standard PCB layouts, making it ideal for electrical equipment, power modules, and industrial control systems.



FAQs of 9.5MM PITCH 2 PIN BARRIER TERMINAL CONNECTOR:




Q: How do I mount the 9.5MM pitch 2 pin barrier terminal connector to a PCB?

A: This connector uses through-hole mounting. Align the pins with corresponding holes on your PCB and solder them securely to ensure both mechanical stability and optimal electrical performance.



Q: What types of wires are compatible with this connector?

A: It supports stranded or solid wire types with gauges ranging from 16 to 22 AWG, offering flexibility for different electrical setups and wire selections.



Q: When should I use this barrier terminal connector in my designs?

A: The connector is best used when reliable, high-current connections are needed, such as in industrial control panels, power distribution boards, or electrical modules requiring secure screw-type terminations.



Q: Where can I source this terminal connector for bulk or customized requirements?

A: You can obtain these connectors from distributors, exporters, importers, manufacturers, or traders throughout India, with options for bulk packaging or custom lengths as per requirement.



Q: What is the process for securing wire connections within the terminal block?

A: Insert the stripped wire into the designated terminal slot, then tighten the M3 screw to a torque of 0.4 Nm maximum, ensuring a secure and reliable electrical contact.



Q: How does the connector benefit my industrial application?

A: Its high current and voltage ratings, flame resistance, and strong mechanical construction provide safe, durable, and low-resistance connections in harsh industrial settings, ensuring long-term reliability.



Q: What measures ensure electrical safety and compliance in this product?

A: It is RoHS compliant, has a dielectric withstand of 2000V AC/minute, and insulation resistance of 500 M minimum at 500V DCensuring compliance with international safety standards for electrical components.
